Electrolux T4900 - Replacing Supporting Rollers

Drum with bearing
Service
manual
78
1
2
A
B B
Replacing supporting rollers
1.Disconnectthepowersupplytothedryer.
2.Openandremovethefilterdoor.
 Fig.1Removethefingerguardbyunscrewing
 the2screwsA, fig.1.
3.Fig.2ServicecoverplatesB.
4.Undothe8screwsineachservicecover 
 plate(donotloosenthemcompletely).
5.Theservicecoverplatesareremoved.
6. Fig.3Openthedoor,liftthedrumandinsert
awedgeCbetweenthefrontandthedrumso
thatthesupportingrollersarerelievedofthe
pressureofthedrum.
7. Fig.4DismountscrewPwithwasher
andbushandsupportingrollerscanbe
dismounted/replaced.
Whenmounting:ProtectthescrewPwith
OmnifitSeal46Morsimilarquality.
TightenthescrewPwith30Nm.
8. Reassemblethedryer.
9.Connectthepowersupply.
Function check
Functioncheckthedryer,seesectionPeriodic
maintenance.
4
3
C
P
