Electrolux T4900 - Electric Heating Unit Types

Heating - electric
Service
manual
74
Electric heating unit types
Heating
effect
48kW
48kW
48kW
60kW
60kW
72kW
72kW
Dryertype

T4900/TD100
T4900/TD100
T4900/TD100
T4900/TD100/T31200/TD135
T4900/TD100/T31200/TD135
T41200/TD135
T41200/TD135
Numberof
elements
6
6
6
10
10
12
12
Voltage
230-240V50/60Hz
400-415V50Hz
400-480V60Hz
400-415V50Hz
400-480V60Hz
400-415V50Hz
400-480V60Hz
Electric heating unit
Electricheatingunitseenfromthefrontwith
openfrontshutter-
fromtheleft,fig.1.
andfromtherightside,fig.2.
1
2
