Electrolux T4900 - Inlet Air Sensor Systems

Sensors and overheating thermostats
Service
manual
42
Overview - inlet air
Positioningofsensorsandoverheatingthermostatsforinletair.
Fig.1a+1bGasandelectricheateddryershave1overheatingthermostatandthermistor
elementonthesideoftheheatingcalorifier.
Fig.2a+2bElectricheateddryershaveanextraoverheatingthermostatplacedontopof
theheatingelements.
Note!Onsteamheateddryersthereisnoinletoverheatingthermostat.
Onthefollowingpagesreplacementandmanualresettingisdescribed.
