Electrolux T4900 - Machine Description and Control

Description of principal components
Service
manual
16
Machine description
DryertypesT4900/TD100andT41200/TD135areavailableaselectric,gasorsteam
heated.TheyaresuppliedwitheitherstandarddoororwithSlidingDoor.SlidingDoor
canalsobefittedwithtiltingfunction.
Programs - Selecta Control
Thedryerhasamicroprocessor.Themicroprocessorcontrolhasdifferentfunctions
including:
•Drumreversingforlesstanglingoflargeitems.
•Ananticreasefunctionwhichengagesaftertheendoftheprogramsequence.
•Dryerfunctionsmonitoring-errorsoccurredduringtheprogramsequenceare 
 registeredinthelog.Someerrorcodesareshownonthedisplayatthesametime.
•Autostop,thedryerstopsautomaticallywhentheclothesaredry.
P
Heatingunit
Gasreset
button
(activeongas
dryersonly)
Operating
controlbox
Standarddoor
Emergencystop
Drum
Filterdoor/filter
Adjustablefeet
