Electrolux T4900 - Adjusting Door Gaskets and Alignment

93
Sliding Door
Service
manual
Adjusting doors (gasket)
Checkthattheloadingdoorgasketis
cleanandingoodcondition.Useasuitable
cleaner.Donotusesolventsthatmay
damagesensitiveplasticsorpaintedfinish.
Fig.1CheckthatthefeltsealingringA is
intactandingoodcondition.
Theremustbeamaximumof2mm
betweensteelframeandfelt.
Fig.2Adjustingofspaceisdoneby
looseningscrewsBholdingglidingshoe
andpushingthedoorsintoplace.
Theremustbeamaximumof2mm
betweensteelframeandfelt.
CheckandtightenallscrewsB (with6Nm)
holdingtheglidingshoes.
1
2
A
Max. 2 mm
B
B
B
B
B
B
B
B
A
B
