Electrolux T4900 - Control Unit

Control
Service
manual
36
1
Relays110VAC:
1.KA: TiltsystemDOWN/doorswitchcircuit
2.KB: Tiltsystemcircuit-rotationispossibleinposition"0"
3.KC: TiltsystemUP
4.KD: Runfrequencycontrol(manualrotation)
5.PCB-5: Indicatorlight(anti-crease-ONforanhour)
6.KQ: Runfrequencycontrol(standardoperation)
Control unit
Tumble dryer with Sliding Door, tilt and frequency
control
ThecontrolunitonadryerwithSlidingDoor,tiltand
frequencycontrolisillustratedbelow.Pleasenotethatit
isa50Hzdryer.
1. 2. 3. 4. 5. 6.
