Electrolux T4900 - Sliding Door Lint Filter Switch

55
Door switch and lint filter switch
Service
manual
1
2
Lint filter switch, Sliding Door
Function
Thelintfilterswitchensuresthatthedryerwillnotoperatewhenthefilterdoorisopen.
Ifthedryerdoesnotoperatewiththelintfilterdoorclosedandlocked,thelintfilterswitch
mightneedreplacing.
Replacement
1.Disconnectthepowersupplytothedryer.
2. Fig.1Openthefilterdoor.
3.Fig.2Unscrewtheswitch.
4.Connectwirestothenewswitch.
5.Mountthenewswitch.
6.Closethefilterdoor.
Testing the lint filter switch
1.Connectthepowersupplytothedryer.
2.Startthedryer.
3.Ifthedryerdoesnotstartwhenthefilterdoorisclosedandthestartbuttonispressed,
 checkthatthefilterdoorisactivatingtheleveronthelintfilterswitch.
 Ifthefilterswitchfails/hangs(withoutdisconnecting)andthefilterdoorisopened,
 falseairisdrawninandthiscancausevacuumerror,errorcode E15.
4.Confirmthatthefan,drumandheatallstopwhenthefilterdoorisopenedduring
 operation.
