Electrolux T4900 - Replacing Wire Rope

Sliding Door
Service
manual
92
Replacing wire rope
1.Disconnectthepowersupplytothedryer.
2.Adjusttwoboardsasillustratedto555mm
forfixationofthedoors.Placethembetween
handleandgirderB.
3.DismountpanelsP infiltercompartment.
4.Loosenall6wireclampsA.
5.Replacedefectivewire.
6. SecurethenewwiretoadjustingscrewJ.
7.SeeAdjusting wire rope earlierinthissection.
8. Mountallpartsandtestthetumbledryer.
1
555mm
A
A
A
B
A
A
J
A
P
