Description of principal components
Service
manual
20
Drum
Thedrumisrearsuspendedinabearing
wherethebearinghousingismountedina
crossbeamontheinnerbackplate.
Thedrumiseithermadeofstainlessor
galvanizedsteel.
SeesectionDrum with bearing.
Loading door
Thedryerhasarightoralefthingedstandard
door,fig.1.orSlidingDoor,fig.2.
Adoorswitchensuresthatthedryerstops
automaticallyifthedoorisopenedduringa
programsequence.
SeesectionDoor switch and filter door
switch.
Motor
Bothdryertypes(900litresand1200litres)
have2motors:
•1drummotor.
•1blowermotor.
SeesectionMotor.
Heating unit
Theheatingunitispositionedinthetopofthe
dryer.
SeesectionHeating system.
Operating control box/panel
Theoperatingcontrolboxorpanel,fig.3,is
equippedwith:
•Buttonsforsettingprograms,temperatures,
 anddryingtime.
•Start/stopbutton.
•Displayshowingprogramselection,remaining
 dryingtimeanderrorcode,ifany.
•Heatingindicator,lamplightswhenheatingis
 on.
SeesectionControl.
1
P
487 19 24 03.02
2
P
487 19 24 03.02
3
