19
Description of principal components
Service
manual
Sliding Door - Tilt
Fig.1Withtiltthedryercantipforwardsat7°
Rotation of the drum
Thedrumcanberotatedwithorwithouttiltand
withthedooropenorclosed.
Gas reset button
Fig.2Openthecontrolpanel.
Thegasresetbuttonislocatedontherearofthe
controlpanelonalldryers.However,itisactive
ongasdryersonly.
7°
1
2
