Description of principal components
Service
manual
18
P
487 19 24 03.02
ROTATION
ROTATION TILT
Tiltingthedryer.
Thetiltingcanbe
disconnectedby
turningtheknobback
touprightposition.
Drumrotationwhile
emptyingthedryer
Rotationofdrumin
bothdirectionsduring
theemptyingprocess.
Indicatorlampfor
endofdryingcycle
Operationcontrol
panel
Knobforadjustingthe
rotationspeedofthe
drum
Options - Sliding Door and tilt buttons and symbols
