Electrolux T4900 - Control Locations for Sliding Doors

33
Control
Service
manual
Control locations
Tumble dryer with Sliding Door
Fig. 1TheSelectaIIprintedcircuitboardisplacedbehindthepanel.
TheSelectaIIprintedcircuitboardcontainsadisplay,indicatorlampsanda
connectorfortheuserkeypad.
Fig. 2 TheSelectaIIprintedcircuitboardalsocontainsabuttonAforchangingto
programmingmode.
SeeSelectaControlServiceManualforprogrammingthedryer.
To be continued
Warning!
High voltage behind the screen
