Control
Service
manual
34
Control locations
Tumble dryer with Sliding Door
Continued
Whenreplacing/repairingthecircuitboardorbuttons,theprotectivescreenandthe
wirebracketmustberemoved:
1.Disconnectthepowersupplytothedryer.
2.LoosenthescrewintheoperatingpanelprotectivescreenBandthenslideit 
 downwards,fig. 3.
3.LoosenthetwoscrewsCinthewirebracketandthenremoveit,fig. 4.
Note!Remembertomountprotectivescreenandthewirebracketafterservice.
Remember to disconnect the power!
Warning!
High voltage behind the screen
3
B
4
C
