Electrolux T4900 - Testing Door Lock on Loading Door Standard Door

Testing door lock on loading door
Standard door
Itmustbepossibletoopenthedoorlockon
theloadingdoorfromtheinsidewithaforce
notexceeding70N(7.1Kp).
Thedoormustbestrainedwithaforce
correspondingtotheabove70N(7.1Kp).
Thestrainmustbedoneasfarfromthedoor
hingeaspossible.
Fig.1Thedoorlockcanbeadjustedwitha
screwdriverinbothendsasindicatedbythe
arrowsA.Remembertoadjustequallyatboth
ends.
A
A
1
51
Door switch and lint filter switch
Service
manual
