Electrolux T4900 - Fan Module Dismounting and Replacement

Motor
Service
manual
60
Dismounting fan module
1. Disconnectthepowersupplytothedryer.
2. Removethebackplate.
3. Fig.1Removethe2screwsAfromthebottomofthedryer.
4. Fig.2Loosenthe4screwsB.
5. Fig.1.DisconnectthemotorplugC.
6. Fig.2.Dismountthewholefanunit.
 Thefanwheelismounteddirectlyonthemotorshaft.
A
B
B
B
C
1
2
