Electrolux T4900 - Vacuum Shutter Switch Function

Sensors and overheating thermostats
Service
manual
48
Vacuum shutter and switch
Active on electric and gas heated dryers only
Function
Thevacuumswitchensuresthenecessaryairflowinthedryer.

Adjustment
Theswitchmustclickwhenthedistancefromthevacuumshutterplatetothebodyofthe
dryerisapprox.7mm.
Ifthedistanceistoobig,thevacuumshuttermightnotcloseproperly.
Vacuumshutterandshutterswitcharelocatedbehindthebackplate.
Fig.1ThetopscrewAontheswitchisusedforadjustingthevacuumshutterdistance
fromthebodyofthedryer.
Error codes
Thefollowingerrorcodesarerelatedtothissection:
E15, E16
SeeSelectaControlServiceManualformoreinformation.
1
7 mm
A
