Electrolux T4900 - Sliding Door Switch Operation

53
Door switch and lint filter switch
Service
manual
Loading door switch - Sliding Door
Fig.1TheswitchBismountednexttothegasresetbuttoninthesidepanel.
Theswitchensuresthatthedryerstopsautomaticallyiftheloadingdoororthepanelis
openedduringoperation.
Ifthedryerdoesnotstopwhentheloadingdoororpanelisopened,theswitchneeds
replacing.
Replacing door switch
1.Disconnectthepowersupplytothedryer.
2.Loosenthescrewintheoperatingpanelcoverandthenslidethecoverdownwards.
3.Fig.1RemovethecabletieAinordertobeabletomovetheoperatingpanelcover.
4.Disconnectthewiresfromthedoorswitch.
5.Fig.1DismountthedoorswitchB.
6.Mountthenewswitch.
7.Connectthewires.
8.Re-assembleandtestthenewswitch,seenextpage.
