Electrolux T4900 - Replacing Locking Plates and Gas Cylinders

Sliding Door
Service
manual
94
Replacing locking plate and gas
cylinder
The2SlidingDoorsarekeptclosedby
alockingplateA-positionedbehindthe
smalllockingplateD-whichengagesina
guidebearingBwhenthe2SlidingDoors
areclosed.
Fig.1Thelockingplateisheldinposition
byagascylinderCwhichisinstalledonthe
reverseofthebar.
Ifthelockingplateorgascylinderis
defectiveitmustbereplaced:
1.Fig.1RemovesmallcoverplateD
2.Fig.2RemovebarEbyundoingthe3
 screwsFoneitherside.
Tobecontinued
1
2
E
E
C
F
B
D
A
