Sliding Door
Service
manual
Continued
3.Fig.3PullthecrossmemberEclockwisein
 ordertoremoveit.
 Fig.4GascylinderCorlockingplateAcan
 nowbereplaced.
4.Fig.5IftheguidebearingBdoesnot
 engageproperlyinthelockingplateA,the
 lockingplate’srearstopcanbeadjusted
 withscrew.
3
E
A
4
5
C
G
A
B
