12
Technical data - type TD100
Heating Gas Steam Electric
Drum volume: (900 litres) 32 cu.ft 32 cu.ft 32 cu.ft
Weight net: Basic: Standard door 1202 lb 1202 lb 1202 lb
Basic: Sliding Door 1321 lb 1321 lb 1321 lb
Heating unit 86 lb 110 lb 93 lb
Drum: Diameter (1240 mm) 48 13/16” 48 13/16” 48 13/16”
Depth (770 mm) 30 5/16” 30 5/16” 30 5/16”
Revolutions per minute 38 rpm 38 rpm 38 rpm
Capacity: (45 kg) 100 lb 100 lb 100 lb
Heat effect: Gas heating (64 kW) 219000 BTU/h
Steam heating Depending upon
steam pressure
Electric heating (48 kW) 164000 BTU/h
Electric heating (60 kW) 205000 BTU/h
Air consumption: 1354 cu.ft./ min 1354 cu.ft./ min 1354 cu.ft./ min
Piping: Exhaust duct (Ø 315 mm) Ø 12” Ø 12” Ø 12”
Piping Gas connection 1” NPT
Steam in ISO 228/1 - G1
Steam out ISO 228/1 - G1
Max counter-pressure: (100 Pa) 0.37” W.C 0.37” W.C 0.37” W.C
Gas pressure: See page regarding
pressure in the installation
manual supplied with the
dryer
Sound pressure level: < 70 dB (A) < 70 dB (A) < 70 dB (A)
