Electrolux T4900 - Maintenance - Internal Wearing Parts

25
Periodic maintenance
Service
manual
Maintenance - Internal wearing
parts
Maintenanceshouldbeconductedtoan
extentrelatedtooperationfrequencyandthe
conditionsonthepremises,oratleastoncea
year.
Cleaning around the drum
Fig.1Cleaningaroundthesupportrollersis
performedthroughthe2serviceholesB.
Fig.1Cleaningaroundthetheuppersection,
emergencystopanddoorswitchcanbe
performedthroughtheserviceholesF.
1.Disconnectthepowersupplytothedryer.
2.Fig.2Openthefilterdoorandremove
 thefilter.Thefingerguardisremovedby
 unscrewing2screwsA,fig.2.
3. ServicecoverplatesB,fig.3.
 Tobecontinued
