Periodic maintenance
Service
manual
26
26
6
4
Continued
4. Undothe8screwsineachservicecover
plate(thescrewsmustnotbecompletely
unscrewed).
5. Fig.4DismountservicecoverplatesB.
6. Openfrontshutter.
Fig.5DismountservicecoverplatesF(the
screwsmustnotbecompletelyunscrewed).
7. Removethelintusingavacuumcleaner.
8. Reassemblethedryer.
9. Connectthepowersupply.
10. Functioncheckthedryer.
Note!
Fig.6Thefiltermustturnsothatthecentrebrace
Minthefilterisvisible.
5
F
F
F
M
