Electrolux T4900 - Selecta II Printed Circuit Board

Control
Service
manual
32
P
1
Selecta II Printed Circuit Board
Tumble dryer with standard loading door
Fig. 1TheSelectaIIprintedcircuitboardisplacedin
theoperatingboxA.
TheSelectaIIprintedcircuitboardcontainsadisplay,
indicatorlampsandaconnectorfortheuserkeypad.
Fig. 2 Theprintedcircuitboardalsocontainsaservice
switchBforchangingtoprogrammingmode.
SeeSelectaControlServiceManualforprogramming
thedryer.
