Electrolux T4900 - Gas Heated Dryer Systems

Heating - gas
Service
manual
66
Gas heated dryers
Description
Thegasburners(2pcs)arelocatedinthegas
heatingunitatthetopofthedryerbehindback
plateA,fig.1.
Theairisdrawnthroughthelouvresonthe
backplateandintotheheatingunit.
Theheatedairpassesthroughthegarments
andthedrumvents.
Fig.2Theairthenflowsfromtheperforation
throughthefilterandviatheoutlettotheopen
air.
Thegasburnerswithignitionelectrodes,
nozzlesandgasvalvesarecontrolledbythe
SelectaControlandthethermostats.
Overheating thermostats
AlsoseesectionSensors and overheating
thermostats.
Gasheateddryersareequippedwithtwo
overheatingthermostatsconnectedinseries,
oneintheinletandoneintheoutlet.
Intheeventofoverheating,thedryerstops
andE08 flashesinthedisplay.
ForresettingseesectionSensors and
overheating thermostats.
Thiserrorisoftencausedbyreductionofthe
aircirculationinthedryerduetonotenough
airintheroomorduetothedryerbeing
overloaded.
Ifthedryerisalsostoppedbeforethecool
downfunctionhasstartedtheafter-heatcan
causetheoverheatingthermostatstoswitch
off.
Thefollowingerrorcodesarerelatedtothis
section:
E 08overheating
E 14 gaserror
SeeSelectaControlservicemanual.
2
1
A
