Electrolux T4900 - Inlet Air Thermostat Reset and Thermistor

43
Sensors and overheating thermostats
Service
manual
Inlet air - overheating thermostat
Function
Theinletoverheatingthermostatopensautomaticallyintheeventofoverheating,and
shutsoffthedryer.Ithastoberesetmanually.
Resetting
Electric heated dryers, fig. 1a+1b
Theoverheatingthermostats(2pcs)arelocatedbehindthefrontshutterofthedryer
-oneonthesideoftheheatingunit1aandonejustabovetheheatingelements1b.
Gas heated dryers, fig. 2
Theoverheatingthermostatislocatedbehindthefrontshutterofthedryer,ontheleftside
ofthegasheatingunit.
Note!Inordertoresetthethermostats,openthefrontshutterandpresstheresetbutton
Aonthethermostats.
Steam heated dryers
Thereisnoinletoverheatingthermostatonsteamheateddryers.
Error code
Thefollowingerrorcodeisrelatedtothissection:
E08
SeeSelectaControlServiceManualformoreinformation.
A
A
A
1a
1b
2
A
