Technical data - type T41200
Heating Gas Steam Electric
Drum volume: 1200 litres 1200 litres 1200 litres
Weight net: Basic: Standard door 580 kg 580 kg 580 kg
Basic: Sliding Door 634 kg 634 kg 634 kg
Heating unit 46 kg 50 kg 42 kg
Motors: Effect: Fan (3-phase) 1.1 kW 1.1 kW 1.1 kW
RPM: 50 Hz 2800 rpm 2800 rpm 2800 rpm
RPM: 60 HZ 3400 rpm 3400 rpm 3400 rpm
Effect: Drum (3-phase) 1.5 kW 1.5 kW 1.5 kW
RPM: 50 Hz 1440 rpm 1440 rpm 1440 rpm
RPM: 60 Hz 1730 rpm 1730 rpm 1730 rpm
Drum: Diameter 1240 mm 1240 mm 1240 mm
Depth 1000 mm 1000 mm 1000 mm
Revolutions per minute 38 rpm 38 rpm 38 rpm
Capacity: 60 kg 60 kg 60 kg
Heat effect: Gas heating 82 kW
Steam heating Depending upon
steam pressure
Electric heating 60 / 72 kW
Air consumption: Max. 2500 m
3
/h Max. 2500 m
3
/h Max. 2500 m
3
/h
Piping: Exhaust duct Ø 315 mm Ø 315 mm Ø 315 mm
Gas connection ISO 7/1 - Rp 1
Steam in ISO 228/1 - G1
Steam out ISO 228/1 - G1
Pressure drop: max. 100 Pa max. 100 Pa max. 100 Pa
Gas pressure: See page regarding
pressure in the installation
manual supplied with the
dryer
Sound pressure level: < 70 dB (A) < 70 dB (A) < 70 dB (A)
