Electrolux T4900 - Replacing Electric Heating Element

75
Heating - electric
Service
manual
Replacing electric heating element
 1.Disconnectthepowertothedryer.
 2.Fig.1Openfrontshutter.
 3.Fig.2RemovescrewsAfrombothsidesofthe
heatingunit.
 4.Fig.2Removethe2barsBandtheheating
elementsarenowloose.
 5.Fig.3Checkthatthedatastamps(kWandV)
onthesideofthenewandtheoldelements
correspondwitheachother.
Markthecables.Carefullydismountthe
cablesmakingsurenottoloosenthecable
terminals.
 6.Mountthenewheatingelementinthe
oppositeorderasdescribedabove.
 7.Remembertoremounttheearthing
conductorsiftheyhavebeendismounted.
 8.Carryoutafunctioncheck,seesection
Periodic maintenance, Function check.
 9.Letthedryeroperateonaprogramwithheat.
3
1
A
B
2
