Technical data - type TD135
Heating Gas Steam Electric
Drum volume: (1200 litres) 42.4 cu.ft 42.4 cu.ft 42.4 cu.ft
Weight net: Basic: Standard door 1279 lb 1279 lb 1279 lb
Basic: Sliding Door 1398 lb 1398 lb 1398 lb
Heating unit 101 lb 110 lb 93 lb
Drum: Diameter (1240 mm) 48 13/16” 48 13/16” 48 13/16”
Depth (1000 mm) 39 3/8” 39 3/8” 39 3/8”
Revolutions per min 38 rpm 38 rpm 38 rpm
Capacity: (60 kg) 135 lb 135 lb 135 lb
Heat effect: Gas heating (82 kW) 280000 BTU/h
Steam heating Depending upon
steam pressure
Electric heating (60 kW) 205000 BTU/h
Electric heating (72 kW) 240000 BTU/h
Air consumption: 5970 cu.ft / min 5970 cu.ft / min 5970 cu.ft / min
Piping: Exhaust duct (Ø 315 mm) Ø 12” Ø 12” Ø 12”
Piping: Gas connection 1” NPT
Steam in ISO 228/1 - G1
Steam out ISO 228/1 - G1
Max. counter-pressure: (100 Pa) 0.37” W.C 0.37” W.C 0.37” W.C
Gas pressure: See page regarding
pressure in the installation
manual supplied with the
dryer
Sound pressure level: < 70 dB (A) < 70 dB (A) < 70 dB (A)
