Electrolux T4900 - Replacing Collector Graphite

RMC
Service
manual
106
Replacing collector graphite
ThepurposeofRMCistobeabletostopthedryerwhenapre-selectedmoisturelevel
hasbeenreachedintheclothes.
FormaintenanceseesectionPeriodic maintenance.
Ifthedryerstopsalmoststraightawaywithouttheclothesbeingdrythisisbecausethe
measuringsystemhasbeendisconnectedwithoutasignalbeingsenttothecontrol,
ie.noerrorcodeisdisplayed.
IfthisoccursthecausemaybethatthegraphitecollectorAandtheglidesurfacesonthe
drumaxleneedcleaning,orthatthegraphitecollectorisdefectiveandhastobereplaced,
g.1.
Toreplacethecollectorgraphite:
1.Disconnectthepowersupplyfromthedryer.
2.Removethebackplate
3. Replaceorcleanthecollectorgraphite
4.Assemblethedryer.
5.Connectthepowerandtestthedryer.
Function check
Checkthedryer,seesectionPeriodic maintenance,Function check.
1
A
