Electrolux T4900 - Belt Tightening and Area Checks

Periodic maintenance
Service
manual
28
Tightening belt
1.Removebackplate.
2.Fig.1Checkthatthespringistightenedas
 shownB
 SpringlengthAshouldbe45mm±1mm.
3.Fig.2Loosenthe4boltsCholdingthemotor
 andmountthebeltbetweenthemotorpulley
 andtheidler
4.Fig.2TightenthescrewsDto230N.
5.Fig.3GaugethebelttensionusingaV-belt
 tensiongauge.
6.Fig.2Tightenthe4bolts C.
1
2
3
D
C
A
B
B
