Dismounting transmission module
Continued
5.Fig.3RemovescrewE(thewholemotorbridgeishangingfromthebeltsC).
6.Fig.4DismountlockingplateGinordertoremovethemotorbridgeshaftF.
7.LiftthebeltsCoffthepulleysandthewholetransmissionmodulewithmotorbridge
 cannowberemoved.
 Motor/transmission/pulleycanbereplacedorfixed.
Tobecontinued
E
3
4
F
G
G
C
E
