Sliding Door
Service
manual
Continued
3.Fig.4Positiontheliftingtackle.
 Itisimportanttopositionthe
 liftingtacklebelowtheback
 bearerC sothecentreofthe
 liftingtacklesupportsthebearer.
 Beforestartingtoliftthedryer
 ensurethatthesupportunderthe
 liftingtackleisstable.
4.Fig.5Startliftingthedryerjusta
 littlebitsotheboltDisreleased
 intheslot.
5.Removeboltsinbothactuators.
6.Turntheactuatorslooseofthe
 fittings.
7.Carefullylowerthedryerinupright
 position.
8.Removetheliftingtackle.
9.Mounttheconnectingpieceatthe
 outletpipe.
10.Mountthebackplateswhich
 weredismountedinstep1.
11.Connecttheoutletpipetothe
 system.
Note! Whenreplacinganactuator,
bothactuatorsmustalwaysbe
replacedasaset.
5
D
4
C
