Phasors
A Phasor is a vector representation of the Voltages & Currents in the system. The Phasor Window of
the BLACKBOX Web Interface represents both Wye and Delta Voltage Configurations in a Phasor
format. Therefore, the Phasors are a vector representation of the First Harmonic.
NOTE NOTE NOTE
In order to display the Phasor graph, ensure that you install the ActiveX plug-in from Gigasoft
(downloadable either from Elspec's Website's Support Section or alternatively can be installed
directly from your BLACKBOX CD). You will receive the following error message if the program
is not installed:
For Internet Explorer 8/9 Users: Once you have installed Gigasoft, ensure that the Internet
Explorer is running in Compatibility View:
open the phasors window:
Access your Portable BLACKBOX Unit via the Web Interface select Monitoring
Phasors:
