About Verifying Measurement Readings
The final step after you have Configured your Device, is to verify the voltage & current
measurements of your Portable BLACKBOX. This verification step covers only a partial section of the
BLACKBOX's Full PQ Monitoring Capabilities. It includes:
 Accessing & Reviewing the Measurement Summary
 Accessing & Reviewing Voltage & Current Measurements
 Accessing & Reviewing the Power
see also:
 Quick Installation
 Unit Powering
 Establish 1st Time Connection
 Plug & Play - Voltage & Current Probes
 Unit Access
 Quick Unit Configuration
 Enable PQZIP Recording
Access the Measurement Summary
The Measurement Summary summarizes all your measurement readings. The most important
parameters you will need to focus on in this window are Phase Order (for 3 phase systems) & DSP
Synchronization:
 Phase Order: Confirms the order of the voltage phases starts from V
1
& are moving in a
clockwise direction
 DSP Synchronization: Confirms that the unit is synchronized with the network
 For a full description on all the definitions & subsequent parameter calculations see PQ
Monitoring
