Emerson DCX S - Page 135

To Next Page

To Previous Page

100-412-183 REV. 13 125

Standard Series

(M8 x 1.25 horn stud)

40 kHz

Aluminum, 1:0.6 (Purple) 101-149-087

Aluminum, 1:1 (Green) 101-149-079

Aluminum, 1:1.5 (Gold) 101-149-080

Aluminum, 1:2 (Silver) 101-149-081R

Aluminum, 1:2.5 (Black) 101-149-082

Titanium, 1:1 (Green) 101-149-085

Titanium, 1:1.5 (Gold) 101-149-086

Titanium, 1:2 (Silver) 101-149-083

Titanium, 1:2.5 (Black) 101-149-084

Table 8.11 DCX S Power Supply Compatible Boosters

Type of Booster Description Part Number
