3.4 Take Inventory of Small Parts
* Mylar is a registered trademark of DuPont Teijin Films.
3.4.1 Cables
The RF cable connects the power supply to the converter. For automated systems you will
also need a user I/O cable to monitor and control the power supply. Check your invoice for
cable types and cable lengths.
Table 3.4 Small Parts included (=x): Power Supply Assemblies
Part or Kit 20 kHz 30 kHz 40 kHz
Mylar®* plastic film Washer Kit X X
Silicone Grease X
Spanners (2) X X X
Table 3.5 DCX S Power Supply System Cables
P/N Description
100-240-383 Cable, RF 8 ft (2.5 m)
100-240-384 Cable, RF 15 ft (4.5 m)
100-240-385 Cable, RF 25 ft (7.5 m)
100-240-387 Cable, RF right angle 8 ft (2.5 m)
100-240-388 Cable, RF right angle 15 ft (4.5 m)
100-240-389 Cable, RF right angle 25 ft (7.5 m)
100-240-391
Cable, RF adaptor for CR20 converter 3 ft
(0.9 m)
100-240-392 Cable, User I/O 25 ft (7.5 m)
200-240-396 Cable Ethernet Cat 5e 7 ft (2.1 m)
100-240-397
Cable, RF adaptor for 4TR converter 3 ft
(0.9 m)
