Emerson DCX S - Table 4.3 Input Current and Circuit Breaker Specifications; Table 4.4 Continuous Duty Max. Power

100-412-183 REV. 13 35
40 kHz
400 W 3 A Max. @ 200 V / 10 A Breaker
800 W 5 A Max. @ 200 V / 10 A Breaker
Table 4.4 Continuous Duty Max. Power
Model Power Continuous Duty Max. Power
20 kHz
1250 W 800 W
2500 W 1600 W
4000 W 2000 W
30 kHz
750 W 300 W
1500 W 800 W
40 kHz
400 W 300 W
800 W 400 W
NOTICE
High duty cycles require additional cooling for the converter. For
information on converter cooling refer to 5.6 Converter Cooling.
NOTICE
System average power must be limited to the specified continuous
maximum. Higher peak power, up to the maximum acceptable power
limit, with an on time of up to 10 seconds may be obtained if
appropriate off time ensures that, on average, the Continuous Duty
Maximum Power is not exceeded.
Table 4.3 Input Current and Circuit Breaker Specifications
Model Power Current Rating
