100-412-183 REV. 13
71
Use the spanner wrench and an open-end wrench (refer to
Figure 5.13
Connecting
Tip
to
Horn
) and tighten to the following torque tip specifications:
Figure 5.13
Connecting Tip to Horn
Table 5.19
Tip to Horn V
alues
Tip Thread
Torque
1/4 - 28
110 in·lbs (12.42 N·m)
3/8 - 24
180 in·lbs (20.33 N·m)
80
82
