3.1 Shipping and Handling
3.1.1 Environmental Specifications
The DCX S Power Supply is an electronic unit that converts line voltage to ultrasonic
energy and responds to user input for regulating the weld process. Its internal
components are sensitive to static discharge, and many of its components can be harmed
if the unit is dropped, shipped under improper conditions, or otherwise mishandled.
The following environmental guidelines should be respected in the shipping of the power
supply.
CAUTION Heavy Object
The power supply may be heavy. Handling, unpacking, and
installation may require the assistance of a colleague or the use of
lifting platforms or hoists.
Table 3.1 Shipping Specifications
Environmental Condition Acceptable Range
Storage / Shipping
Temperature
-25º C / -13º F to +55º C / +131º F (+70º C /
+158º F for 24 hours)
Shock / Vibration (transit)
45 g shock / 0.5 g and (3 to 100 Hz) vibration per
ASTM 3332-88 and 3580-90
Drop Test ISTA Procedure 1 & 2A (while packaged)
Humidity Maximum 95%, non-condensing
