100-412-183 REV. 13 87

Figure 6.9 40 kHz Converter/Booster/Horn, Typical Dimensions

* Overall horn length can vary beyond these typical dimensions depending on the application.

** Dimension varies with tuning and gain.

Table 6.9 40 kHz Converter/Booster/Horn, Typical Dimensions

Item Description

1 Converter

2 Booster

3 One-half wavelength horn

4 Recommended clamping area

Booster front end diameter will vary with

amplitude
