100-412-183 REV. 13 65
5
Connect the converter-booster-horn stack to the power supply using the RF
cable. See 5.3.15 Output Power (RF Cable) Connection.
6
Ensure the power switch on the back of the unit is in the OFF position. Plug
the connector block back into the power supply. Tighten the two securing
screws.
7
Connect the power supply to a single-phase, grounded, 3-wire, 50 Hz or
60 Hz 200 V to 230 V power source.
Table 5.12 Input Power Connection
Step Action
