Emerson Rosemount 5402 - Emerson Wireless THUM Adapter

98
Reference Manual
00809-0100-4026, Rev KC
Operation and Maintenance
October 2018
Operation and Maintenance
4.13.3 Emerson
™
Wireless THUM
™
Adapter
The Rosemount 5400 can be combined with the THUM Adapter.
For more information, see the Wireless THUM Adapter Technical Note and the Reference Manual.
Figure 4-22. Wiring Diagram for a Rosemount 5400 with the THUM Adapter
A. Rosemount Field Communicator E. RRM/Rosemount Configuration Tool
B. 4-20 mA/HART F. DCS/host system
C. Rosemount 5400 with THUM Adapter G. AMS Suite configurator
D. Wireless Gateway
E
F
A
B
C
D
G
