Reference Manual
00809-0100-4026, Rev KC
Mechanical Installation
October 2018
Mechanical Installation
3.4.7 Parabolic antenna with threaded connection
Figure 3-24. Components
A.
B.
C.
Lock nut
Antenna adapter with ball joint
O-ring
D.
E.
F.
Antenna
Threaded sleeve
M20 adapter
G.
H.
G3/8" bonded seal
Blind plug
2x
1x 1x
1x
1x
1x 1x
A
B
C
D
1x
F
1x
E
G
H
