Reference Manual
00809-0100-4026, Rev KC
Configuration
October 2018
Configuration
5.5 Configuration using a Field Communicator
This section describes the configuration of a Rosemount 5400 with a Field Communicator.
The menu tree with the various configuration parameters is shown in Figure 5-15 on page 131.
Section “Basic configuration parameters” on page 101 describes the basic configuration parameters.
See sections “Echo tuning” on page 109 and Appendix C: Advanced Configuration for information on
disturbance echo handling and advanced configuration.
For information on all the capabilities, see the 375 Field Communicator User’s Manual or the 475 Field
Communicator User’s Manual, available at FieldCommunicator.com
.
Figure 5-13. 375 Field Communicator
A. Navigation keys E. Function key
B. Tab key F. Alpha numeric keypad
C. On/Off key G. Backlight adjustment key
D. Enter key
E
A
G
D
B
C
F
