Level Transducer Block
Appendix E Level Transducer Block
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 281
Parameters and descriptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 282
Supported units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 289
Diagnostics device errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . page 290
E.1 Overview
This section contains information on the Rosemount
™
5400 Level Transmitter Transducer Block (TB).
Descriptions of all Transducer Block parameters, errors, and diagnostics are listed.
E.1.1 Definition
The transducer block contains the actual measurement data, including a level and distance reading.
Channels 1–6 are assigned to these measurements. The transducer block includes information about
sensor type, engineering units, and all parameters needed to configure the radar gauge.
E.1.2 Channel definitions
Each input has an assigned channel which can be linked to the AI block. The channels for the Rosemount
5400 are the following:
Table E-1. Channel Assignments
Channel name Channel number Process variable
Level 1 RADAR_LEVEL
Ullage 2 RADAR_ULLAGE
Level Rate 3 RADAR_LEVELRATE
Signal Strength 4 RADAR_LEVEL_SIGNAL_STRENGTH
Volume 5 RADAR_VOLUME
Internal Temperature 6 RADAR_INTERNAL_TEMPERATURE
