Reference Manual
00809-0100-4026, Rev KC
Mechanical Installation
October 2018
Mechanical Installation
3.4.11 Tri Clamp tank connection
1. Lower transmitter with antenna into the tank.
2. Fasten Tri Clamp to the tank with a clamp.
3. Adjust display orientation (optional).
Gasket
Torque
30 Lbft (40 Nm)
