Emerson Rosemount 5402 - Parabolic Antenna with Welded Connection

50
Reference Manual
00809-0100-4026, Rev KC
Mechanical Installation
October 2018
Mechanical Installation
3.4.6 Parabolic antenna with welded connection
Figure 3-23. Components
A.
B.
C.
D.
E.
Weld protection plate
Weld protection bar
Flange ball
O-ring
Clamp flange
F.
G.
H.
I.
J.
Washer
M8 screw
Antenna
Ball joint
Threaded sleeve
K.
L.
M.
M20 adapter
G3/8" bonded seal
Blind plug
2x 1x 1x
1x
1x
1x 1x
1x
1x
3x 3x
A
B
C
D
E
F
G
I
H
1x
K
1x
J
L
M
