Mechanical Installation
1. Mount protection plates to flange/manhole cover.
These plates protects the internal surfaces of the flange ball from welding sparks.
Ø 3.94 ± 0.02 in.
(Ø 100 ± 0.5 mm)
A
C
B
A
Max. 1.18 in. (30 mm)
