Emerson Process Management GmbH & Co. OHG 6-19
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
6
Software Menus
6.2.2.8 Data Logger
6.2.2 Control Menu
Control..
Data logger..
Data Logger
Export Data to USB!
Cached Entries 10
Total Entries 120
If the system is setup accordingly, the access
code for level 1 must be entered to gain ac-
cess to this menu.
Enter this menu to export data logger data to
an external device for further processing.
Number of entries currently in RAM, not yet
saved to the internal data logger (total entries)
le.
Note!
Data is written to the internal le every 30 min,
or the moment, "Logging" is turned Off (SE-
TUP - DATA LOGGER; 6-105 )
Total number of entries in the internal data
logger le.
Export logged data (=total entries) to an USB
device.
Notes!
Make sure, there´s a memory device con-
nected!
Before the data is exported, all "Cached ent-
ries" are copied to the "Total entries" le.
