6.2.3 Setup Menu
6.2.3.3.3.3.2 Calculate Polynomials
Ch1
LinearSetpoints..
CalcPolySet: All poly
Calculate!
Cancel!
State Poly1 No coeffs
State Poly2 No coeffs
State Poly3 No coeffs
State Poly4 No coeffs
Merit
0
Ch1
 Approximation setup
MaxItera: 100
Cut-off: 0.001
Submenu for linearization setpoints (
below )
Ch1
Linearization setpoints
Setpoints (X)..
Actuals (Y)..
RefPoly1: 10000 ppm
RefPoly2: 10000 ppm
RefPoly3: 10000 ppm
RefPoly4: 10000 ppm
Clear all points!
6.2.3.3.3.3.2.1 Linearization Setpoints
Submenu to enter setpoints (
6-51 ).
Submenu to enter actuals (
6-52 ).
Start calculation of polynomials.
Clear all entered setpoints.
